Ball impact resistant acoustic ceilings

Ball impact resistant acoustic ceilings  handle the room acoustics and fire protection at the same time.

In sports and gambling halls, which are often used for meetings, festivities or discussions, a considerable noise can develop. We have the remedial measures.  Our 27 tested systems, combine different products,including various  finishes and fixtures,

Technical installations are often located behind the facing panels. . It is very important that the ceiling void can be accessed   easily for adjustments or repair work. , We have audited access panels available for all systems and surfaces,. All impact-resistant systems of BER are in accordance with DIN 18032, Part 3, tested and withstand permanently the required mechanical stresses. Likewise, our ceiling systems are available according to the requirements of DIN EN 13964, Annex D, tested for impact resistance. They belong to the most resilient Class 1A. When being tested  with a sub-standard ball shot machine, 36 shots are fired at the ceiling with a handball, the impact speed is about 16.5 ± 0.8 m / s or 60 km / h.

Preventive fire protection plays a very important role in these venues. According to DIN EN 13501-1 or DIN 4102, we have,Hence we provide our ball impact resistant constructions of  non-combustible, non-flammable and normally inflammable products.



Holz-F Type S



Holz-F Type L
